Yorkville Sound - Coliseum Series Compact Speaker - 8 inch Woofer 150 Watts - White

The compact 150-watt C190 is capable of delivering a full 70 to 20,000 Hz frequency response. This proven 8-inch woofer and horn design uses an injection molded 90 x 30 degree horn assembly with 1.4-inch titanium driver.

Yorkville's ingenious self-resetting PTC high frequency protection circuit protects the high frequency components used in the C190. PTC offers serious advantages over protection schemes used in many loudspeaker cabinets. While always present in the signal path, remains inaudible until it becomes necessary for it to react, at which point it effectively reduces output to the horn, protecting it from damage due to excessive power input or signal distortion. Unlike a breaker it does not require a physical reset to allow signal back to the horn driver, and unlike a bulb or fuse, does not need to be replaced if the circuit is tripped, and the fuse is blown, making it the ideal high frequency protection scheme for an installation loudspeaker.

A polemount socket and nine integrated 3/8-inch flypoints allow the C190 to be installed or flown easily and on virtually any angle without modification to the speaker. The all-metal grille protects the loudspeaker components while the all-metal input plate supports both 1/4-inch and binding post connectors.

All enclosures and grilles can be easily refinished and many have the option of coming in either a black or white finish. Designed for fixed installation or live use, the Coliseum Mini Series like the C110, C170 and WM5T have a complete list of features that make them an extremely good value. The practically configured C110 incorporates a multi-tap 70V transformer for fixed installations while the waterproof C120 is perfect for indoor or outdoor application as a loudspeaker or can be mounted on a microphone stand as a mini monitor. The WM5T in-wall speaker is a clean, high performance solution that is sure to solve space constraint issues. Basic mounting hardware is included with most models.

Features:
• 150 Watts / 8 ohms
• Ultra Compact Cabinet Design
• 8-inch Woofer / 1.4-inch Titanium Horn Driver
• 90 x 30 Rotatable Horn
• Self Resetting PTC High Frequency Driver Protection
• Nine Integrated 3/8-inch flypoints
• 3/4-inch MDF Cabinet Construction
• All Metal Grille / Integrated Standmount Adaptor
• 1/4-inch & Binding Post Inputs
• Available in White (C190W) or Black (C190) finishes

Specifications:
• System Type: 2-Way
• Active or Passive: Passive
• Program Power (Watts): 150
• Biampable: No
• Nominal Impedance (Ohms): 8
• Sensitivity (dB @1Watt/1m): 91
• Max SPL (dB): 113
• Frequency Response (Hz +/- 3dB): 70 - 20k
• Crossover Frequency (Hz): 1800
• Driver Configuration: 8 inch / 1.4 inch
• HF Driver(s): 1.4 inch Aluminum (1 inch Throat)
• HF Horn: Injection Molded ABS
• HF Dispersion ( DEG H x DEG V): 90 x 30
• HF Protection: PTC
• LF Driver(s): 8 inch Ceramic
• LF Program Power(Watts): 150
• Inputs - 1/4 IN Jacks: 2
• Inputs - Binding Post: 1
• Flying Hardware: 3/8 inch x 5 (Purchased Seperately)
• Pole Mount Adapter (1 3/8 IN -3.5cm): Yes
• Enclosure Materials: 3/4 inch MDF
• Grille: White Perforated Metal
• Covering / Finish: White Painted
• Dimensions (DWH xbackW COM inches): 12.75 x 10 x 18 x 8.25
• Dimensions (DWH xbackW COM cm): 32.4 x 25.4 x 45.7 x 21
• Weight (lbs/kg): 26 / 11.8
