ISP Technologies - Michael Sweet Empyrean Preamp Pedal

Like all Mark Bass products, this was also developed to meet the needs of musicians. With its 3-channel the PRO BASS MIXER is a brilliant choice for musicians (not only for bassists) who use more than one instrument and need separate controls for each one. The compact section of each channel includes Gain and Volume controls, Hifizer and Old School filters, and an output selector switch that allows to select between OUT 1 and OUT 2. Plus, on channel 3 a switchable 48V Phantom Power to use a Condenser Mic. It's possible to connect the OUT 1 and OUT 2 to LINK1 and LINK2 of other PRO BASS MIXERs, making virtually unlimited the number of channels available.

Pro Mixer in a stompbox
The BASS PRO MIXER feats 3-channel, designed for who use more than instruments and need to have different setting/controls
for each of them. Everything in a super-pratical stompbox, that also allows to turn on/off each channel via footswitch and more.

Linkable design
The BASS PRO MIXER design allows to connect in link more of them, making the number of channels available unlimited.

Output Selector
Each channel features an Output Selector that allows to choose to which of the two outs you like to send that channel signal, for
very versatile applications.

Simple ed effective controls, Hifizer and Old School Filters
The BASS PRO MIXER features on each channel Gain and Volume controls to optimize the level of each signal, plus the Hifizer (a Pre Shape filter, Minimum at 700 Hz, From 0 to 25 dBfilter) that boosts lows and highs, and cuts mids giving hi-fi tone(especially great for slap and pick playing) and the Old School filter (Frequency range 450 Hz 20 Khz) that as its name said give you a mellower, less modern sound.

Phantom Power
The 48V phantom power featured on the combo jack input of CH3 allows you to use the XLR input with a condenser microphone or with active pickup systems that us a balanced XLR output.

Specifications
- Channels: 3
- IN CH1 (1/4" jack) and IN CH2 (1/4" jack): Impedance 1M?, max. voltage 5 Vpp
- IN CH3 (combo jack) UNBALANCED BALANCED: Impedance 22K?, max. voltage 5 Vpp / Impedance 2K?, max. voltage 6 Vpp
- Other Inputs: LINK 1 (1/4" jack) and LINK 2 (1/4" jack)
- Phantom Power (48V): on CHANNEL 3 (with on/off switch)
- Controls (each channel): Gain, Volume, Hifizer, Old School
- Output Selector: Switch OUT 1 / OUT 2 (on each channel)
- Outputs: BALANCED OUT 1 (with GND) and BALANCED OUT 2 (with GND) / OUT 1 (1/4" jack) and OUT 2 (1/4" jack)
- Power Requirement: 9 to 12VDC (120mA (power supply included))
- Dimensions: 6.1 x 5 x 2.05" (15.5 x 12.7 x 5.2 cm)
- Weight: 1.83 lb (830gr)
